Our S-Beam modules handle weighing and force measurement across many industries for weights ranging from fractions of pounds to tons. These modules are capable of dynamic and static compression and tension. The standard S-Beam and Mini S-Beam support many industrial and consumer applications, including:
- Small Silo and Tank Weighing
- Robotics and Cobotics
- Testing Systems
- Industrial Scales
- Packaging and Batching Systems
Need a Custom Solution?
Contact UsFeatures & Benefits
- Aluminum and Alloy Steel Construction
- Stainless Steel Available
- Wide Range of Capacities
- Hermetically Sealed Options
- Explosive Protection Options
- Multiple Capacities (0.25lb~10lb)
Technical Specifications
View All Model Details
BSS-ESH (S-type) V17.3
BSS (S-type) V17.3
BSS-ESH (S-type) V17.3
| Specifications | |
|---|---|
| Rated Output | 2.0-3.0mV/V ±0.1% |
| Safe Temp. Range | -10ºC to + 70ºC |
| Zero Balance | ±1% of rated output |
| Temp. Compensated | -10ºC to + 40ºC |
| Creep after 30 minutes | ±0.03% of rated output |
| Safe Overload | 150% |
| Nonlinearity | ±0.03% of rated output |
| Input Impedance | 387 ohm ± 20 ohm |
| Hysteresis | ±0.03% of rated output |
| Output Impedance | 350 ohm ± 5 ohm |
| Repeatability | ±0.03% of rated output |
| Insulation Resistance | ≥5000 M ohm (50V DC) |
| Temp. effect on output | ≤0.002% of applied output/ºC |
| Rated Excitation | 10V DC/AC |
| Temp. effect on zero | ≤0.002% of rated output/ºC |
| Maximum Excitation | 15V DC/AC |
| Wire Length | 6m |
| Wire Material | Red(+E) Black(-E) White(-S) Green(+S) |
BSS (S-type) V17.3
| Specifications | |
|---|---|
| Rated Output | 2.0-3.0mV/V ±0.1% |
| Safe Temp. Range | -10ºC to + 70ºC |
| Zero Balance | ±1% of rated output |
| Temp. Compensated | -10ºC to + 40ºC |
| Creep after 30 minutes | ±0.03% of rated output |
| Safe Overload | 150% |
| Nonlinearity | ±0.03% of rated output |
| Input Impedance | 387 ohm ± 20 ohm |
| Hysteresis | ±0.03% of rated output |
| Output Impedance | 350 ohm ± 5 ohm |
| Repeatability | ±0.03% of rated output |
| Insulation Resistance | ≥5000 M ohm (50V DC) |
| Temp. effect on output | ≤0.002% of applied output/ºC |
| Rated Excitation | 10V DC/AC |
| Temp. effect on zero | ≤0.002% of rated output/ºC |
| Maximum Excitation | 15V DC/AC |
| Wire Length | 6m |
| Wire Material | Red(+E) Black(-E) White(-S) Green(+S) |
| BSS-ESH S-type V17.3 | View Sheet |
| BSS S-type V17.3 | View Sheet |
