JB-FI-4 Excitation Trim Junction Box

$60.00

16 in stock (can be backordered)

Product Description

Our JB-FI is a load cell summing card housed in an ABS enclosure. It has four 5-position terminal strips for load cell input and one 7-position terminal strip with internally jumped sense terminals for output to the instrument. The board will sum 2 to 4 load cells and can be daisy-chained to sum up to 8 load cells using 2 summing cards and enclosures. Trimming of excitation is accomplished with  multi-turn trim pots. A stainless steel enclosure version (JB-SS) is also available. Summing card (JB-PCB) can be purchased separately and measures 100 mm x 75 mm.

SKU: 102000290 Category:

Dimensions
