SBSB Series Single Ended Shear Beam Load Cell
| Compression only Designed for pushing force measurement · hermetically sealed · stainless steel construction |
|
| Same-day shipping In-stock orders ship the same business day · Free 2-day delivery |
|
| Manufacturer direct Designed & supported by Transcell in Buffalo Grove, IL since 1981 |
|
| 2-year limited warranty US-based technical support included · repair or replace guarantee |
Product Description
SBSB single-ended shear beam load cell overview
The SBSB is a stainless steel, hermetically sealed single-ended shear beam load cell engineered for compression-only force measurement in demanding industrial environments where the alloy steel SBS is not sufficient. Its fully welded stainless steel construction provides superior corrosion resistance and long-term signal stability in washdown, chemical, food processing, and outdoor applications where moisture, cleaning agents, or harsh environmental conditions are present. Sharing the same single-ended cantilever geometry as the SBS, the SBSB bolts at one end while the platform or load structure bears down on the free end, making it a direct stainless steel upgrade path for existing SBS installations. Available from 1,000 lb to 10,000 lb, the SBSB is a direct drop-in replacement for the most widely used stainless steel shear beam models on the market.
|
Capacity range
1,000 lb
up to 10,000 lb
|
Nonlinearity
±0.03%
of rated output
|
Construction
SS
hermetically sealed
|
Safe overload
150%
of rated capacity
|
Typical applications
The SBSB is specified wherever the SBS geometry is required but the environment demands stainless steel construction — washdown facilities, food processing, chemical plants, and outdoor installations.
|
|
|||||
|
|
|||||
|
|
Technical notes
|
Installation and mounting
The SBSB mounts via bolt holes at the fixed end, with the load applied downward at the free (cantilevered) end. The mounting surface must be flat, rigid, and level for accurate readings. Side loading and off-axis forces should be minimized. Use check rods or anti-rotation restraints where horizontal forces or vibration are present. For multi-cell platform scale installations, mount one SBSB at each support point and use a summing junction box to balance and combine the outputs before connecting to the indicator. |
System integration
The SBSB operates at a rated excitation of 10V DC/AC (15V max) and produces a 2.0 or 3.0 mV/V analog output signal. It is compatible with any standard weight indicator, PLC analog input, or load cell conditioner accepting a mV/V bridge input. For multi-cell installations, a load cell summing junction box is used to balance and combine signals from each cell before passing a single output to the indicator. |
|
Rated output
2.0 – 3.0 mV/V ±0.1%
|
Zero balance
±1% of rated output
|
Nonlinearity / Hysteresis
±0.03% RO each
|
Temp. effect on output
≤0.002% /°C
|
|
Safe temp. range
−10°C to +70°C
|
Insulation resistance
≥5,000 MΩ at 50V DC
|
Input impedance
387 Ω ± 20 Ω
|
Output impedance
350 Ω ± 5 Ω
|
|
Cable wiring
The SBSB ships with a 6 m (20 ft) cable. Standard color code:
|
Drop-in replacement for
The SBSB is a direct mechanical and electrical substitute for the following stainless steel shear beam load cell models. No wiring or mounting changes are required when upgrading or replacing:
|
Dimensions / 3D Drawings
Note: You may need a software that can open/view STEP files.
-
Data Sheets
Download Now
Interchangeable
Related Products
-
Free 2-Day ShippingSBS Series Single Ended Shear Beam Load Cell (lb, NTEP)
Price range: $185.00 through $575.00 Select options This product has multiple variants. The options may be chosen on the product page
Ask us about our OEM and Dealer Pricing
